Product Information:
Black Copper BC-98AC Features and Benefits
Features:
Black Copper BC-98AC Description
Features
● 200mm/s high printing speed.
● ESC/POS compatible, setting DIP switch to choose characters and fonts.
● Better sealing performance for mechanism and printer, Mechanism life can reach to 100km and Auto cutter life with 1.5 million cuts.
Specifications
| |
Printing |
| |
Printing method |
Direct thermal |
| |
Print width |
72mm |
| |
Column capacity |
576 dots/line 512 dots/line (80mm) |
| |
Printing speed |
200mm/s |
| |
Interface |
USB+Serial / Lan |
| |
Printing paper |
79.5±0.5mm |
| |
Line spacing |
3.75mm (Adjustable by commands) |
| |
Column number
|
80mm paper: Font A - 42 columns or 48 columns/Font B - 56 columns or 64 columns/
Chinese,traditional Chinese - 21 columns or 24 columns |
| |
Character size
|
ANK，Font A：1.5×3.0mm（12×24 dots） Font B：1.1×2.1mm（9×17 dots） Chinese,traditional Chinese:3.0×3.0mm（24×24 dots） |
| |
Cutter |
| |
Auto cutter |
Partial |
| |
Barcode Character |
| |
Extension character
sheet |
PC347（Standard Europe）、Katakana、PC850（Multilingual）、PC860（Portuguese）、PC863（Canadian-French）、PC865（Nordic）、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251） |
| |
Barcode types |
UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128 |
| |
Buffer |
| |
Input buffer |
64k bytes |
| |
NV Flash |
256k bytes |
| |
Power |
| |
Power adaptor |
Input：AC 110V/220V, 50～60Hz |
| |
Power source |
Output：DC 24V/2.5A |
| |
Cash drawer output |
DC 24V/1A |
| |
Physical characteristics |
| |
Weight |
1.05 KG |
| |
Dimensions |
190×140×136mm ( D×W×H) |
| |
Environmental Requirements |
| |
Work environment |
Temperature (0～45) humidity(10～80%) |
| |
Storage environment |
Temperature(-10～60℃) humidity(10～80%) |
| |
Reliability |
| |
Cutter life |
1.5 million cuts |
| |
Printer head life |
100KM |
