Printing
|
Print Method
|
Thermal Transfer / Direct Thermal
|
|
Print Resolution
|
300 DPI
|
|
Print Speed
|
2~6 inch/s (51-152mm/s)
|
|
Max. Print Width
|
108 mm(4.25")
|
|
Max. Print Length
|
2286mm (90")
|
|
Dot Density
|
300dots/inch (12dots/mm)
|
|
Dot Size
|
0.125x0.125mm (1mm=11.8dots)
|
|
Interface
|
USB+Parallel+Serial+Ethernet
|
|
Ribbon
|
Ribbon OD
|
Max.67mm
|
|
Ribbon Length
|
Max.300m
|
|
Ribbon Core Size
|
1 inch (25.4mm)
|
|
Ribbon Width
|
Max.110mm, Min.30mm
|
|
Ribbon Rolling Up Method
|
Outward Rolling
|
|
Media
|
Paper Roll OD
|
127mm (5")
|
|
Paper Type
|
Continuous paper, Marked paper, Label paper, Perforated paper, etc.
|
|
Paper Rolling Up Method
|
Printing side outward rolling
|
|
Paper Width
|
Max.120mm (4.72") Min.20mm (0.78")
|
|
Paper Thickness
|
Max. 0.254mm (10mil) Min. 0.06mm (2.36mil)
|
|
Paper Roll Core Size
|
25.4mm~38mm (1"~1.5")
|
|
Paper Gap
|
Min. 2 mm (0.09")
|
|
Label Length
|
10~2286mm (0.39"~90")
|
|
Remark: If label length is less than 25.4mm(1 inch), the label paper with perforated line are recommended in order to tear off the labels easily.
|
|
Specifications
|
Printer Dimensions
|
290x196x179mm (LxWxH)
|
|
Printer Weight
|
Approx. 2.5KG
|
|
Power
|
Input: AC 110V/240V Output: DC24V/2.5A，60W
|
|
Operation Condition
|
Temperature: 5~45℃(41~104℉), Humidity: 25~85%RH
|
|
Storage Condition
|
Temperature: -10~50℃(-10~140℉), Humidity: 10%~90%RH
|
|
Print Head
|
50KM
|
|
Software
|
Editing Software
|
Nicelabel SE
|
|
Driver
|
Windows 2000, XP, Vista, Win7, Win8, Win10, Windows Server 2003&2008
|
|
DLL
|
Windows 2000, XP and Vista
|
|
Fonts
|
Enlargement&Rotation
|
1 to10 times enlargement in both directions; 0°、90°、270°、360°rotation
|
|
Character Size
|
FONT O to FONT 8
|
|
Barcode
|
1D Barcode
|
Code39, Code93, Code128UCC subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8
|
|
EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, china
|
|
POS, ITF14
|
|
2D Barcode
|
QR code
|
|
|
Graphics Processing
|
Support BMP/PCX/BAS files
|
|
Accessories
|
Standard External Media Holder
|
