Shape features
|
Aluminium case,black, color touch screen
|
|
Dimension
|
113*140*185 mm
|
|
Definition
|
300PDI
|
|
Printing direction
|
Adjustable with 360 degree, meet all kinds of production needs
|
|
Printing line
|
1-8 lines (adjustable)
|
|
Printing height
|
1.2mm-12.7mm
|
|
Printing distance
|
1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2-5mm)
|
|
Printing content
|
Chinese, English, number, date, time, QR code, bar code, picture
|
|
Application
|
Board, carton, stone, pipe, cable, metal, plastic, electronics, automotive parts
|
|
Printing length
|
no limitation on length
|
|
Printing speed
|
60m/min
|
|
Ink type
|
Quick-dry environmental ink, water-based ink and oily ink
|
|
Ink color
|
black, white, red, blue, yellow, green, invisible
|
|
Ink volume
|
42ml (usually can print 800,000 characters)
|
|
Interface
|
USB, RS232, DB15, Photoelectric interface, Bluetooth 4.0, Wi-Fi
|
|
Voltage
|
DC16.8 lithium battery
|
|
Storage
|
the system can store more than 1000 mass (external USB make the information transfer in a free way)
|
|
Working condition
|
Temperature:0 - 45 degree; Humidity: 10% - 80%
|
